R1000
- RMS Power (Per Channel,8Ω) 350W
- RMS Power (Per Channel,4Ω) 550W
- Rated Power (Bridge 8Ω) 960W
- Output Circuity: CLASS AB
Description
R1000
- R1000: 350W into 8ohms; 550W into 4ohms; 960W into 8ohms(Bridged)
- Precision Power, Signal, CLIP, PROT to monitor performance
- Independent limiters per channel offer reliable protection against overload and distortion.
- Independent DC and thermal protection on each channel automatically protects the amplifier and speaker
- without shutting down the show.
- “Front to rear” ventilation system avoids uncomfortable feelings when operating the amps from the front panel.
- Good quality electronic elements and extraordinarily robust construction ensure a long life span.
- Works perfectly even at low voltage, specifically “Make for India”.
- Designed by AERONS INDIA, India.
Specifications
|
Rated Power (1 KHz, THD+N=0.1% |
8Ω stereo 2x350W 4Ω stereo 2x550W 8Ω bridge 960W |
|
Frequency Response (1W 8Ω stereo) |
20Hz ̴ 20KHz(±2dB) |
|
Sensitivity (8Ω stereo @1Khz) |
0.775V/1V/1.4V |
|
Mode |
Stereo/Parallel/Bridge |
|
Input connectors |
XLR (Neutrik®) |
|
Output connectors |
Speakon (Neutrik®) |
|
Filter Capability |
100V 10000uFx4 |
|
Input Impedance
|
Balanced 20K Unbalanced 10K |
|
Channel separation |
≥65dB |
|
Slew Rate |
≥15V/µs |
|
S/N ratio |
≥97dB |
|
Damping Factor |
≥150 |
|
Output Circuitry |
Class AB |
|
Dimension (W x H x D) |
550x410x190 mm |
|
Gross Weight |
14.5Kg |
